Deck Framing Calculator — Joists, Beams and Footings

The frame under the boards: how many joists at your spacing, the posts and footings to hold them up, and — the part that matters — whether the joists you picked can actually span the distance.

By The OneTripDIY Team · Updated

ft

The side along the house. Joists sit across this dimension.

ft

How far it projects from the house. This is the distance each joist has to span.

Joists — pieces
Each joist — ft
Max span for this joist —
Span check —
Posts — no.
Footings — no.
Beam length — ft
Joist hangers — no.
Deck area — sq ft

Estimates only. Check against your supplier's stated coverage before you buy.

Take this list to the store

We'll email the quantities above, what you typed in, and a link that reopens this calculator already filled in — so you can adjust it on your phone in the aisle.

We send the list you asked for. Anything else only if you tick the box, and you can unsubscribe in one click. What we do with it.

Joists at 16 in. on centerCount is the run divided by the spacing, plus one for the last one.Joists at 16 in. on center16 in."top plateon center means center to center, not the gap between them.Count = width ÷ spacing, plus one for the last one.

How to work it out

  1. Set the two dimensions

    Width is the side along the house; depth is how far the deck sticks out. Joists run the depth direction, so depth is the span each one has to cover — and span is what decides the joist size.

  2. Count the joists

    Width in inches divided by the spacing, plus one for the last joist. A 16 ft deck at 16 in. centers is 192 ÷ 16 = 12, plus one, so 13 joists. Add the two rim joists that close the ends and you are ordering 15 pieces.

  3. Check the span before you buy

    This is the step that matters. A 2 × 8 southern pine joist at 16 in. centers can span 11 ft 10 in.; hem-fir can only manage 10 ft 11 in. Go past it and the deck is bouncy at best. The calculator tells you whether your depth fits, using the IRC table.

  4. Work out posts and footings

    A post every eight feet along the beam is a conservative starting point that suits most small decks. Every post needs a footing below the frost line, sized for the load it carries and the soil it sits on. Both of those are local questions — ask before you dig.

Maximum joist span — southern pine

IRC 2021 Table R507.6. 40 psf live plus 10 psf dead, no cantilever.

Joist12 in. OC16 in. OC24 in. OC
2 × 69 ft 11 in.9 ft 0 in.7 ft 7 in.
2 × 813 ft 1 in.11 ft 10 in.9 ft 8 in.
2 × 1016 ft 2 in.14 ft 0 in.11 ft 5 in.
2 × 1218 ft 0 in.16 ft 6 in.13 ft 6 in.

Span is the clear distance a joist covers between supports, not the length of the board.

Maximum joist span — hem-fir and SPF

Same loading. Softer species, shorter spans.

Joist12 in. OC16 in. OC24 in. OC
2 × 69 ft 6 in.8 ft 4 in.6 ft 10 in.
2 × 812 ft 6 in.10 ft 11 in.8 ft 11 in.
2 × 1015 ft 8 in.13 ft 7 in.11 ft 1 in.
2 × 1218 ft 0 in.15 ft 9 in.12 ft 10 in.

If you do not know what species you bought, look at the grade stamp on the board. If you cannot find it, assume the shorter figures.

How far can a deck joist span?

A 2 × 8 southern pine joist at 16 inch centers spans 11 ft 10 in. A 2 × 10 gets you to 14 ft, and a 2 × 12 to 16 ft 6 in. In hem-fir or SPF, knock roughly a foot off each of those.

Span is measured between supports — the clear distance from the ledger to the beam — not the length of the board you buy. A joist that spans 12 feet is usually a 14 foot board once you account for bearing and the bit hanging past the beam.

Closer spacing buys less than you think

Going from 16 inch centers to 12 gains about a foot of span on a 2 × 8 and costs you a third more joists. Going up a size — 2 × 8 to 2 × 10 — gains over two feet for the same number of pieces.

Deeper joists are almost always the better trade. Use 12 inch spacing when the decking needs it, which is the usual reason: diagonal patterns and most composite boards specify it, and that requirement has nothing to do with the joist span.

Posts, beams and where the load goes

Joists carry the deck to the beam; the beam carries it to the posts; the posts carry it to the footings; the footings spread it into the ground. Every one of those hand-offs has to work, and the footing is the one people skimp on.

A post every eight feet is a reasonable starting assumption for a small deck and that is what the calculator uses. Beam size depends on post spacing and how much deck it is carrying — a doubled 2 × 10 in southern pine spans about 9 ft 9 in. with four feet of deck on either side. Beyond a small deck, have it specified.

The ledger is where decks fail

More decks come off houses at the ledger than break anywhere else. It has to be bolted through the rim joist of the house with the specified fasteners at the specified spacing, and it has to be flashed so water cannot sit behind it.

Nails are not enough. Lag screws into siding are not enough. If you cannot see what the ledger is bolted to, find out before you build on it — and if the deck is freestanding instead, that is a legitimate answer that avoids the problem entirely.

What this calculator will not tell you

Beam sizing, footing diameter, post size, lateral bracing, and whether your soil will carry the load. Those depend on things a web page cannot see — frost depth, soil bearing capacity, snow load, and what your inspector wants.

This gives you the piece counts and a span check against the published table, which is enough to price the job and catch the common mistake of a joist that cannot reach. A deck is a structure people stand on. Get the plan looked at.

How this is worked out

No black box — here is the arithmetic the calculator runs, so you can check it against your own numbers.

  1. joists = (width in inches ÷ spacing) + 1 The +1 is the joist at the far end. Two rim joists are counted on top.
  2. span = deck depth Joists run out from the house, so depth is the distance each one covers.
  3. max span from IRC 2021 Table R507.6 By joist size, spacing and species, at 40 psf live and 10 psf dead.
  4. posts = (width ÷ 8) + 1, minimum 2 A post every 8 ft is a conservative starting point for a small deck.
  5. hangers = joists × 2 Both ends of every joist, at the ledger and at the beam.

Common questions

How far apart should deck joists be?

Sixteen inches on center is standard and suits most decking. Twelve inches is needed for diagonal patterns and for many composite boards — check what your decking manufacturer requires, because it is their requirement, not a structural one.

How far can a 2 × 8 deck joist span?

11 ft 10 in. in southern pine at 16 in. centers, or 10 ft 11 in. in hem-fir and SPF. At 12 in. centers it goes to 13 ft 1 in. and 12 ft 6 in. respectively. These are IRC figures at 40 psf live load with no cantilever.

How many joists for a 16 × 12 ft deck?

Thirteen at 16 in. centers, each 12 ft long, plus two rim joists. The 12 ft depth is within a 2 × 8 southern pine span but over the hem-fir limit, so species matters on that one.

Do I need a hanger at both ends of every joist?

At the ledger, yes. At the beam it depends: joists sitting on top of a beam are bearing on it and need hurricane ties rather than hangers, while joists framing flush into the beam need hangers. The calculator assumes hangers at both ends, which is the more expensive assumption.

What size footings does a deck need?

It depends on the load each one carries and what the soil will bear, and both vary too much for a general answer. They must reach below the frost line. Your local building department will tell you the minimum diameter and depth for your area — ask before you dig, not after.

Can I use 2 × 6 joists?

For a small deck close to the ground, yes — 9 ft at 16 in. centers in southern pine. For anything deeper you will be adding a beam mid-span to break the distance up, at which point a 2 × 8 or 2 × 10 is usually cheaper and simpler.

Does decking direction change the framing?

It changes the spacing requirement, not the joist size. Boards laid diagonally cross the joists at 45 degrees, so the effective span of the board increases by about forty per cent — which is why diagonal decking wants 12 in. centers.

Should the deck be attached to the house or freestanding?

Attached is normal and fine when the ledger is done properly. Freestanding avoids the ledger entirely, which removes the single most common point of failure, at the cost of an extra beam line and more posts. On an older house where you cannot establish what the rim joist is, freestanding is worth the extra materials.

Where these figures come from

Every figure below is traceable. How we check the numbers explains how they are verified, and the coverage reference collects them all in one place.

  • International Residential Code 2021, Table R507.6 — deck joist maximum spans
  • International Residential Code 2021, Section R507 — ledger attachment, beams and footings
  • American Wood Council, DCA 6 — prescriptive residential deck construction guide

Think a number here is wrong? Tell us — we check every report, correct the page, and date the change. Last checked September 15, 2026.
